MC Series Horizontal Multistage Centrifugal High Pressure API 610 BB4 Chemical Pumps

Product Detail

Product Description MC series horizontal multistage centrifugal pumps. Balance drum, disc type, balancing axial thrust. Radial bearing and angular-contact bearing gather together to bear the rest force. Cartridge mechanical seal design. Standard API610 Flush and cooling. According to different temperature of the liquid to select right structure, feet support and central bearing. Smart arrangement of suction and discharge can meet different demands. Design different hydraulic models to expand BEP area to ensure pump work in high efficiency at different work condition. Suction type first stage impeller improves anti-cavitations performance. Easy and convenient maintenance design comforts clients. CW viewed from drive end. Product advantage Compact structure, convenient operation, stable operation, easy maintenance, high efficiency, long service life, and a self-priming function etc In pipeline no need to install bottom valve, before work only to ensure the pump body reservoir has led to a quantitative liquid. Simplifies the pipeline system, and improves the working conditions Running Data Specification DN40-200 outlet dia. Capacity: up to 600 m /h Head: up to 1200 m Pressure: 15.0 MPa Temperature: -80 ~+180℃
